StarClear Plus Cartridge Filter 90 Sq.Ft.
Hayward
SKU: C9002
StarClear Plus single element cartridge filters offer excellent quality, value and convenience.
Features
StarClear Plus filters offer quality, value and convenience in cartridge filtration. Because of their durable construction, they can handle the most demanding applications and environmental conditions. The precision engineered core provides extra strength and maximum flow. StarClear Plus filters deliver proven performance and value.
Features and Benefits
• Filter tanks made from durable glass reinforced co-polymer material to meet the demands of the toughest applications and environmental conditions, including in-floor cleaning systems
• Single piece injection-molded base and body provides added strength for reliable, corrosion-free performance
• Single locking knob securely fastens head to filter tank, eliminating bolts or clamps
• Extra-large cartridge element with precision engineered core provides extra-strength and maximum flow
• Elevated, filtered water collector and debris sump prevents accidental by-pass of heavy debris to pool when cartridge is removed for cleaning
• 2" FIP connections for plumbing versatility
• 1⁄2" FIP filter drain for fast draining. Also accepts a standard spigot valve
Features and Benefits
• Filter tanks made from durable glass reinforced co-polymer material to meet the demands of the toughest applications and environmental conditions, including in-floor cleaning systems
• Single piece injection-molded base and body provides added strength for reliable, corrosion-free performance
• Single locking knob securely fastens head to filter tank, eliminating bolts or clamps
• Extra-large cartridge element with precision engineered core provides extra-strength and maximum flow
• Elevated, filtered water collector and debris sump prevents accidental by-pass of heavy debris to pool when cartridge is removed for cleaning
• 2" FIP connections for plumbing versatility
• 1⁄2" FIP filter drain for fast draining. Also accepts a standard spigot valve

- EXPERT LINE products can only be purchased through you local pool professional or in-store.
- 3+ Year Parts and Labor Warranties*
*When sold by a Totally Hayward® partner. Exclusions, other terms and conditions may apply.
Brand | Hayward |
---|---|
Cartridge | Yes |
Channel | Expert Line |
Clearance for head removal | 19 in |
Design Flow Rate | 90 |
Drain Port Size (Inches) | 1/2 FIP |
Effective Filtration Area | 90 SQFT |
Filter Type | Cartridge |
Footprint | 15 x 15 INCH |
GTIN | 610377205818 |
Labor Warranty | 1-year |
Master Carton Qty | 1 |
Number of Filter Elements | 1 |
Pallet Qty | 18 |
Parts Warranty | 3-year |
Pool Type | In Ground |
Pressure Gauge | Yes |
Product Dimensions | 30 " x 13.375 " x 13.375 " |
Product Height | 30 in |
Product Length | 13.375 in |
Product Weight | 26 lb |
Product Width | 13.375 in |
Public Design Flow Rate | 34 |
Quantity | 1 |
Residential Design Flow Rate | 90 |
Series Filters | StarClear Plus |
Shipping Dimensions | 32.1 " x 13.8 " x 13.8 " |
Shipping Height | 32.1 in |
Shipping Length | 13.8 in |
Shipping Weight | 26 lb |
Shipping Width | 13.8 in |
Side Clearance - Filters | 18 in |
Tank Type | GFR |
Turnover 10 Hours | 20250 GPM |
Turnover 8 Hours | 16200 GPM |
Valve Included | N/A |
