HCF Series 48" Bobbin-Wound Sand Filter



The large-format HCF Series sand filters are designed to provide the ultimate in filtration performance and durability.


The large-format HCF Series sand filters are designed to provide the ultimate in filtration performance and durability. Larger sizes eliminate the need to use multiple smaller filters, meaning you’ll save valuable floor space and reduce installation and plumbing complexity—and simplify maintenance and backwashing, too. Constructed with heavy-duty filament-wound fiberglass, a UV-protected resin and corrosion-proof internals, the large-format HCF Series sand filters offers a powerful, streamlined filtration solution for the recreational water market.


» Large-format filters eliminate the need for multiple smaller filters, saving valuable space while providing flow rates up to 433 GPM
» Reduced installation and plumbing complexity with simplified maintenance and backwashing
» Manufactured from heavy-duty filament-wound fiberglass for high-performance filtration and long-lasting durability
» UV-protected resin coat and corrosion-proof internals protect the filter from from even the harshest environments
» Large manway mechanism with positive seal enables easy inspection
» Durable fiberglass base for sturdy installation
» Industrial-grade laterals and quad diffusers improve filtration and lengthen filter cycle time
nsf certification logo

NSF Certified

NSF’s comprehensive inspection, testing and certification services ensure our products comply with all major state and provincial health codes, as well as model building and construction codes.

Backwash Flow Rate 268
Brand Hayward
Cartridge No
Channel Open Line
Design Flow Rate 268
Effective Filtration Area 13..4 SQFT
Filter Type Sand
Footprint 48 x 48"
GTIN 610377404051
Master Carton Qty 1
Maximum Working Pressure 50 PSI
Parts Warranty 5-year
Pool Type Commercial
Pressure Gauge Yes
Product Dimensions 58 " x 48 " x 48 "
Product Height 58 in
Product Length 48 in
Product Weight 275 lb
Product Width 48 in
Public Design Flow Rate 268
Residential Design Flow Rate 268
Sand Capacity 2250 lbs
Series Filters HCF
Shipping Dimensions 0 " x 0 " x 0 "
Shipping Height 0 in
Shipping Length 0 in
Shipping Weight 0 lb
Shipping Width 0 in
Side Clearance - Filters 18 in
Turnover 10 Hours 160800 GPM
Turnover 8 Hours 128640 GPM
Valve Included Not Included
Vertical Clearance Filters 18 in
